GMP232/3 CC 120V 5A

Manufacturer: Bachmann electronic GmbH
Manufacturer item no: 00025968-00
Product no.: Bachmann_00025968-00
Product condition: New


Bachmann GMP232/3 CC | Grid measurement and protection module for cold climate
Ask for quoted price.

Bachmann GMP232/3 CC 120V 5A | Grid measurement and protection module for cold climate

  • 3x In 120V - 3x In 5A
  • 2x Out Relay 24/48V DC - 230V AC
  • U-/ I-/ P-/ Q-/ F-measurement
  • 4Q-energy metering - integrated monitoring/protection functions - harmonic analysis - integrated realtime data recorder (24 channels)
  • Data aggregation - sequence of event log with realtime stamp
  • Cold Climate

Bachmann GMP232/3 CC 120V 5A | Grid measurement and protection module for cold climate

  • Measurement of current, voltage, frequency, power, power factor, phase angle
  • True RMS and fundamental RMS, symmetrical components
  • High dynamic measurement
  • Measurement of grid harmonics up to the 50th (PQ)
  • Monitoring functions for grid and generator protection
  • Direct relay outputs for circuit-breaker/trip circuits
  • Integrated real-time data recorder
  • Integrated event logging
  • 4Q energy counter
  • Integrated average values, grid statistics
  • Measured value simulation

Please do refer to the product sheet for more details.
